7 Increasing/Switching Measurement Scenes
7 - 12
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
7-6 Increasing the Number of Scenes in a
Group to more than 128 Scenes
[Conversion Scene Group Data Tool]
You can increase the number of scenes in a scene group to more than 128 scenes.
To start the Conversion Scene Group Data Tool, select [Conversion scene group data tool] from the
[Tool] menu.
Normally, there are 128 scenes in a scene group.
For example, if you need to create scenes for each model and there are more than 128 models, you
would normally create more than one scene group to manage the scenes.
However, you can use the Conversion Scene Group Data Tool to increase the number of scenes in a
scene group to up to 1,024 scenes. A scene group data file (extension *.sgp) is used as the target data.
The ability to manage all of the scenes in one scene group even if there are more than 128 scenes sim-
plifies the PLC control programming and data management.
Important
If you increase the data size of a scene group, you may not be able to save the data in the Con-
troller or load the data from a file, depending on the number of scenes and the settings.
If that occurs, change the measurement flow, separate the scene group, or otherwise reduce
the data size of the scene group.
Additional Information
For best results, organize the scenes in the scene groups before you use the Conversion
Scene Group Data Tool. For example, arrange the scenes in the proper order, delete unneces-
sary scenes, and assign scene names.
Refer to 7-3 Editing Scenes [Scene Maintenance] on page 7-6.
