9 Saving/Loading Data
9 - 30
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
9 The following [Confirm] dialog is displayed. Click the [OK] button to restart the Sensor Control-
ler.
This section explains possible error messages that may be displayed while using Configuration Copy,
as well as possible solutions.
 Errors that may occur when loading.
During the loading of a sensor controller’s project, the following error message is displayed.
(example) Loading of settings data file failed.
• To continue the loading of the Sensor Controller's project
Click [Continue] button.
Loading of the sensor controller will continue, however, the settings data that caused the error
message to display will not be applied.
• To cancel the loading of the sensor controller's project
Click [Interrupt] button.
Loading of the sensor controller will stop. After stopping, you can refer to the troubleshooting list
to find the possible cause and solution for the problem.
After that, initialize the sensor controller, and then reload the sensor controller's project.
Troubleshooting list
9-7-4 Troubleshooting
Phenomenon Cause Action
An error message occurred
because the Sensor Con-
troller's project cannot be
saved.
Save destination is not set. Set the save destination.
Name of the Sensor Controller's
project is not entered.
Enter the Sensor Controller project name.
An empty capacity of the exter-
nal storage is insufficient.
• Change to an external storage device with
larger memory capacity.
• Delete the unnecessary files.
