A-1 Menu List
The menu for the Main Window is described below.
Main
menu
Command Description Reference
File End Exits the FH/FHV/FZ5 System.
After you exit the system, restart the sys-
tem or turn OFF the power supply.
---
Function Measure Executes a test measurement (single or
continuous measurement), or a re-mea-
surement.
Refer to 6-1 Executing Test Measure-
ments on page 6-3.
Refer to 6-4-1 Remeasuring Saved
Images [Remeasurement] on page
6-27.
Scene switch This button switches between scene
groups and scenes:
Refer to 7-2 Switching the Scene or
Scene Group on page 7-4.
Scene mainte-
nance
Used to copy, delete, and rename scenes
and scene groups.
Refer to 7-3 Editing Scenes [Scene
Maintenance] on page 7-6.
Refer to 7-4 Editing Scene Groups
[Scene Maintenance] on page 7-8.
Edit flow Used to edit measurement flows. Refer to 5-5-2 Editing Processing
Units in a Scene on page 5-24.
Switch layout Changes the layout number to display. Refer to 8-3-1 Arranging Window Ele-
ments (Layout Modification) on page
8-14.
Clear measure-
ment
Clears the measurement data. Refer to 6-6-2 Clearing Measurement
Results [Measurement Clear] on
page 6-41.
Clear logging
Clears the images that are logged in the
Controller.
Refer to 6-6-3 Clearing Saved
Images [Logging Image Clear] on
page 6-41.
Screen capture Captures the screen that is being dis-
played.
Refer to 3-5 Capturing Screen
Images on page 3-32.
Saving last log-
ging image
Logs the most recent input images that are
being displayed.
Refer to 6-3-1 Logging Measurement
Values and Measurement Images
[Data Logging/Image Logging] on
page 6-8.
Data save Saves settings data to the flash memory in
the FH/FHV/FZ5.
Refer to 3-6-1 Saving the Setting to
the Controller [Data Save] on page
3-34.
Refer to Saving/Loading Data (P.9-1).
Save to file Saves the settings data, logged images,
and logged data to a file. It also copies
files between memory devices.
Refer to Saving/Loading Data (P.9-1).
Load from file Loads a settings file.
System initial-
ization
Restores the Controller to the default set-
tings.
Refer to 3-7 Initializing the Controller
on page 3-39.
System restart Restarts the Controller. Refer to
3-6-3 Restarting the Control-
ler:
[System Restart
] on page 3-37.
Refer to Saving/Loading Data (P.9-1).
