8 Setting Windows
8 - 30
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
This pane is for measuring and re-measuring. The following elements are displayed. There are no edit-
able elements.
• [Camera image meas.] tab page: [Measure] button
• [Image file meas.] tab page: [Selection image] button, [Re-meas.] button, [Auto Re-meas.] check box,
and the [Judgement result monitor] check box
• [Output] check box
• [Continuous meas.] check box
This pane shows the measurement flow.
The following elements are displayed.
• [1st. NG unit] button
• [Next NG unit] button
• [ ] "Property setting" button
• Measurement flow list
Use the following procedure if the type of settings dialog box to display when you click a processing unit
icon is set to the Simplified Non-stop Adjustment Mode:
1 In Layout Modification Mode, click the icon in the upper right corner of the Flow Display
Pane.
8-3-7 Measurement Pane
8-3-8 Flow Display Pane
Changing the size of the Flow Display Pane
