9 Saving/Loading Data
9 - 12
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
9-5 Copying or Moving Files between the
Controller RAMDisk and an External
Storage Device
You can copy or move files between the Controller RAMDisk and an external storage device.
Images and data saved on the RAMDisk are deleted if the power supply is turned OFF.
To keep these images and data, copy or move them to an external storage device.
The types of files that can be copied/moved are as follows:
• Setting data: System data, Scene data, and Scene group data
• Logged images
• Logged data: Measurement data
1 Insert an external storage device in the Controller.
2 In the Main Window, select [Save to file] from the [Function] menu.
The [Save to file] dialog box is displayed.
3 Click [Copy files] and select the file or folder to copy or move.
4 To delete the copy source file after saving a copy to external storage, select [Delete original data
after save].
5 Click [OK].
The dialog box showing transfer status is displayed, and the data is sent to the save destination.
Parameter
Set value
[Factory default]
Description
Select file [Select folder] Copies or moves more than one file in the folder.
• Click the [...] button and specify the source folder to
copy or move a file from.
• Click the [] button and specify the file type to select.
Select [All files] to copy or move all files in the folder.
Specify a file type to copy or move only files that are of
the specified file type in the folder.
Select file name Copies or moves the selected file.
Click the [...] button and specify the file name.
