Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
A-16 List for Processing Item Identifier
 Measurement
 Input image
Note An item with* in the head is not displayed.
 Compensate image
Processing item Identifier Processing item Identifier
Search Search Flexible Search FlexibleSearch
Sensitive Search SensitiveSearch ECM Search EcmSearch
Shape Search II ShapeSearch2 Shape Search III ShapeSearch3
Ec Corner EcCorner Ec Cross EcCross
Classification Classification Edge Position EdgePosition
Edge Pitch EdgePitch Scan Edge Position ScanEdgePosition
Scan Edge Width ScanEdgeWidth Circular Scan Edge
Position
CircularScanEdgePosition
Circular Scan Edge
Width
CircularScanEdgeWidth Intersection Intersection
Color Data ColorData Gravity and Area ColorArea
Labeling ColorLabeling Label Data LabelData
Defect Defect Precise Defect PreciseDefect
Fine Matching FineMatching Character Inspection CharacterInspect
Date Verification DateVerification Model Dictionary ModelDictionary
2DCode II 2dcr2 2DCode 2dcrV400
Barcode BarcodeCC OCR User Dictionary CharacterDictionary
OCR CharacterRecognition Circle Angle CircleAngle
Glue Bead Inspection EmbrocationTrack
Processing item Identifier Processing item Identifier
Camera Image Input CameraImage Camera Image Input
FH
CameraImageFH
Camera Image Input
FHV
CameraImageFHV
Camera Image Input
HDR
CameraImageHDR Camera Image Input
HDR Lite
CameraImageHDRLite
Photometric Stereo
Image Input
CameraImagePS Camera Switching CameraSwitch
Measurement Image
Switching
MeasureImageSwitch Multi-Trigger Imaging MultiImaging
*Multi-Trigger Imaging
End
MultiImagingEnd Multi-Trigger Imaging
Tas k
MultiImagingTask
Processing item Identifier Processing item Identifier
Position Compensation Scroll Filtering Filtering
Background Suppres-
sion
FilterHighContrast Brightness Correct Fil-
ter
FilterShading
Color Gray Filter FilterColorGray Extract Color Filter FilterExtractColor
Anti Color Shading FilterEven Stripes Removal Filter
II
FilterRank
Polar Transformation TransPolar Trapezoidal Correction TrapezoidalCorrection2
Machine Simulator MachineSimulator Image Subtraction DifferenceExtract
Advanced filter FilterAdvanced Panorama Panorama2
