10 Advanced Usage
10 - 36
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
You can save user account and user group settings (security settings). You can load or delete saved
settings.
Account setting data is not included in BKD files.
You can save user account and user group settings to a RAM disk or an external storage device.
• During data transfer to external storage, do not remove the external storage device until the
transfer is completed. Data and the external storage may be corrupted.
• Timing for Saving Data in the Controller
Data is saved to the Controller only when the [Security setting] dialog box is closed with the
[Close] button.
When the login window is ended by selecting [Cancel], data is not saved to the Controller.
The set contents or loaded contents are cleared by when the Controller is restarted.
• Remote Operation Security
The security settings are synchronized, but for users who are logged in, the security settings
are managed separately on the local side and remote side. Therefore, even if users are
logged in on the local side, they must log in again on the remote side.
1 When saving data to external memory, insert an external storage device into the Sensor Con-
troller.
2 In the Main Window, select [Security settings] from the [Tool] menu.
The [Security settings] dialog box is displayed.
3 Click the [Setting data] tab in the Item Tab Area.
4 Specify the destination folder and file name in the [Save to file] area.
5 Click the [Save] button.
10-3-4 Saving/Loading/Deleting the Security Settings
Saving Security Settings
To Next Page
