8 - 35
8 Setting Windows
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
8-3 Arranging Windows [Layout Functions]
8
8-3-11 Error Pane
• Part of image panes can exceed the Image Container Pane horizontally. They cannot entirely
be positioned outside the Image Container Pane. The upper left part of the image pane will
always stay inside the Image Container Window. No portion of image panes can be posi-
tioned outside the Image Container Pane vertically.
• Available Image Pane numbers differ for the layouts 0 to 7 and for the layout 8. Therefore,
change of Image Panes for the layout 0 to 7 does not apply to the layout 8.
This pane shows errors, such as Camera connection errors.
If you add an Error Pane to a layout and an error occurs that normally causes an error dialog box to
appear, an error string will appear in the Error Pane.
This is useful for remote operation or situations where an error dialog box would be difficult to close.
The latest error string (error message) is displayed on the top line of the error pane.
Also the error pane can display the error messages of up to 100.
The Error Pane is assigned to layout 8 by default.
Setting item
Setting value
[Factory default]
Description
Alignment
Fit to the grid line
•[Unchecked]
• Checked
Selects whether or not to show the grid in the Image Container
Pane.
Checked: The grid will be shown. The size and position of
the window parts will be adjusted according to the
grid.
Unchecked: The grid will be hidden.
Grid interval 2 to 200 [8] Sets the grid size in pixels.
Aspect ratio
Fix the aspect ratio Height: 1 to 9999
[3]
Width: 1 to 9999 [4]
Sets whether or not to fix the aspect ratio of image pane.
The aspect ratio can be adjusted according to that of con-
nected camera.
Checked: The size will be changed with fixed aspect ratio.
Unchecked: The size will be changed without fixing the aspect
ratio.
•[Unchecked]
• Checked
8-3-11 Error Pane
