8 Setting Windows
8 - 26
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
The operation of the output signals in each state is as follows. Set it as necessary.
You can change the layout in the Main Window to the layout number that was set in Layout Modification
Mode.
Use this when you need to work with more than one layout.
1 Select [Switch layout] on the [Function] menu or from the tool buttons.
2 Select the layout number to switch to and click the [OK] button to close the [Switch layout] dialog
box.
Additional Information
It is also possible to switch the Layout number with a communication command.
Setting item
Setting value
[Factory default]
Description
Layout Layout name (up to 32 characters)
RUN signal out
• [Unchecked]
• Checked
The RUN signal is turned on when the box is checked.
Output
• [Not control]
•OFF
•ON
Sets whether or not to output the execution results of the
Result output processing units.
Not control: The state of the outputs that were in effect before
the layout was changed is retained. If [Output] is
selected just before the layout is changed, the
outputs stay ON, and if [Output] is not selected,
the outputs stay OFF.
ON: Data is output when a Results output processing
unit is executed in the measurement flow during
execution of a measurement.
OFF: Data is not output even when a Results output
processing unit is executed in the measurement
flow for a measurement.
State
Layout 0, 2 to 7
displayed
*1
*1. In the default setting, the check box of the “RUN signal output” for layout 1 and 8 is not displayed.
Just after switch-
ing scenes /lay-
outs
At startup
Output condition for output
signal
Follow the “Output”
setting in the
measurement
window.
Follow “RUN signal
output” on “Layout
setup” dialog.
Follow the setting of [Startup layout] of
[Basic] on [System Settings] in [Tool]
menu.
For the selected layout in the “Layout
setup” dialog, the output is not
performed when the “Output” setting is
“No Control”.
8-3-3 Switching Layout Numbers in the Main Window [Layout Switch-
ing]
Setting item
Setting value
[Factory default]
Description
Layout number 0 to 8 Layout number
