10 - 5
10 Advanced Usage
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
10-1 Remotely Operating the Controller
[Remote Operation]
10
10-1-1 Environment Settings
The following preparations are required on the Sensor Controller and a remote operation PC respec-
tively to launch the remote operation.
• Sensor Controller: Set up a server for the remote operation.
• Remote operation PC: Arrange communications and GUI environments for the remote operation.
Install the Remote Operation Tool to the remote operation PC.
Precautions for Correct Use
Make sure that the software version installed on the remote operation PC should be the same
as that on the Sensor Controller.
The recommended operating conditions for the remote operation PC are below.
To use the remote operation tool, Microsoft .NET Framework 3.5 must be installed.
Precautions for Correct Use
In the remote operation, the following port numbers are used to communication with the Sensor
Controller.
• 9900 + Line number (e.g. port 9900 for line 0)
• 9910 + Line nubmer (e.g. port 9910 for line 0)
• 9920 + Line number (e.g. port 9920 for line 0)
Line Numbers: FH: 0 to 7, FH-L/FHV/FZ5: 0 to 1
If these ports are disabled due to security settings of your PC or the domain security policy, the
remote operation is not available.
Reconsider the security settings of your PC or the domain security policy, or ask your domain
security administrator.
10-1-1 Environment Settings
Recommended Operating Conditions for the Remote Operation PC
Name Description
CPU Intel Pentium Processor (SSE2 or higher)
OS Windows 7 Professional (32/64 bit)
or
Enterprise (32/64 bit)
or
Ultimate (32/64 bit), Windows 10 Pro (32/64 bit)
or
Enterprise (32/64 bit)
Memory 2 GB (3 GB or more recommended)
Free capacity in hard disk 2 GB or more
Display Resolution: 1,280 x 1,024 dots or higher
Display color: True Color (32 bits)
Network 10BASE-T compatible network (100BASE-TX recommended)
To Next Page
