7 Increasing/Switching Measurement Scenes
7 - 10
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
7-5 Saving Scene Groups in External
Storage [Scene Group Saving Desti-
nation Settings]
The scene group storage location specification function lets you specify a location other than the Sen-
sor Controller’s flash memory for saving scene group data. After specifying the desired storage location
with this function, menus and buttons such as “Data save”save set data in the specified external stor-
age instead of in the Sensor Controller’s flash memory. This function is handy as it enables use of the
external storage when the volume of scene group data is too large to save all of it in the Sensor Con-
troller’s flash memory.
This function can not be used with the FHV series.
1 Select [Scene Group Saving Destination Setting] from the [Tool] menu in the main screen.
A screen for specifying the scene group storage location appears.
2 Set each item in the [Scene group saving destination on settings] area.
Variable name Set value [Factory default] Content
Scene Group Sav-
ing Destination
Setting
• [Save all scene group data in
the flash memory]
• Save all scene group data in
the external storage device
• Save after the next scene
group data in the external stor-
age device
Sets the storage location for scene group data.
• Store all in Sensor Controller memory
• Store all in an external storage device
• Store scene groups after scene group below in an
external storage device
