Appendices

A - 14

Vision System FH/FHV/FZ5 Series User’s Manual (Z365)

This method extracts parts with color changes as edges to perform measurement.

Edges are found through color changes in the measurement region.

A-5-3 Edge Detection Measurement

When calculating the X coordinate of this edge

Measurement

region

Default Chapter16
- Table of Contents16
Sections in this Manual17
