8 Setting Windows

Vision System FH/FHV/FZ5 Series User’s Manual (Z365)

8-2 Adjustment Windows and Run Windows

8-2-4 Main Window (Layout 1): Switching to the Adjustment Window

1 In the Main Window (layout 1), click the [Switch layout] button in the Toolbox Pane.

2 In the [Switch layout] dialog box, select the layout number (layout 0 by default).

The display changes to the Main Window (layout 0).
