xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
100
Interval (1-2147483647)
The time in seconds between notifications. Value range to use is 1 to 2147483647.
History Size (1-500)
The maximum number of entries listed in the history log used for notification. Up to
500 entries can be specified.
Unit
Select the unit you want to configure.
From Port / To Port
Select the starting and ending ports for MAC notification.
State
Enable MAC Notification for the ports selected using the drop-down menu.
Click the Apply button to accept the changes made for each individual section.
MAC Address Aging Time Settings
Users can configure the MAC Address aging time on the Switch.
To view the following window, click L2 Features > FDB > MAC Address Aging Time Settings, as show below:
Figure 4-47 MAC Address Aging Time Settings window
The fields that can be configured are described below:
Parameter Description
MAC Address Aging
Time (10-1000000)
This field specify the length of time a learned MAC Address will remain in the
forwarding table without being accessed (that is, how long a learned MAC Address
is allowed to remain idle). To change this option, type in a different value
representing the MAC address’ age-out time in seconds. The MAC Address Aging
Time can be set to any value between 10 and 1000000 seconds. The default
setting is 300 seconds.
Click the Apply button to accept the changes made.
MAC Address Table
This allows the Switch's MAC address forwarding table to be viewed. When the Switch learns an association
between a MAC address, VLAN and a port number, it makes an entry into its forwarding table. These entries are
then used to forward packets through the Switch.
To view the following window, click L2 Features > FDB > MAC Address Table, as show below:
