xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
248
BGP Community List Settings
This window is used to configure the matching rules for a BGP community list.
To view the following window, click L3 Features > BGP > BGP Community List Settings, as shown below:
Figure 5-135 BGP Community List Settings window
The fields that can be configured are described below:
Parameter Description
List Name
Enter an Autonomous System path access list name.
Type Use the drop-down menu to select Standard or Expanded. Standard configures a
standard community list and Expanded configures an expanded community list.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the View All button to display all the existing entries.
Click the
View Detail
Click the Delete button to remove the specific entry.
link to view more information regarding the specific entry.
Click the
View Detail link to see the following window.
Figure 5-136 BGP Community Rule Settings - View Detail window
The fields that can be configured are described below:
Parameter Description
Mode
Use the drop-down menu to permit or deny the routes if rule is matched.
Regular Expression
Enter the community set value. This value can be up to 80 characters long.
