xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
76
VID
Enter a VLAN ID.
VID List
Enter a list of VLAN IDs.
IPv4 Network Address
The user can enter the IPv4 address used in here. Remember to include the subnet
mask using the / notation.
IPv6 Network Address
The user can enter the IPv6 address used in here. Remember to include the subnet
mask using the / notation.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete button to remove the specific entry based on the information entered.
Click the Show All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
VLAN Precedence Settings
This window is used to configure VLAN precedence settings.
To view the following window, click L2 Features > VLAN > Subnet VLAN > VLAN Precedence Settings, as show
below:
Figure 4-18 VLAN Precedence Settings window
The fields that can be configured are described below:
Parameter Description
Select the starting and ending ports to use.
VLAN Precedence Use the drop-down menu to select the VLAN precedence as MAC-based VLAN or
