xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
159
Parameter Description
IP Address
Enter the source IP address of the received IP multicast packet matches this
Subnet Mask
Enter the subnet mask of the above specified IP address. If the source IP address
of the received IP multicast packet matches the IP address and subnet mask, RPF
RPF Address
Enter the RPF address. If the source IP address of the received IP multicast packet
matches the IP address and subnet mask, RPF address will be used to check
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
Click the Delete button to remove the specific entry.
Route Preference Settings
This window is used to configure the route type preference. The route with smaller preference has higher priority.
The preference for local routes is fixed to 0.
To view the following window, click L3 Features > Route Preference Settings, as shown below:
Figure 5-11 Route Preference Settings window
Click the Apply button to accept the changes made.
ECMP Algorithm Settings
This window is used to configure the ECMP OSPF state and ECMP route load-balancing algorithm.
To view the following window, click L3 Features > ECMP Algorithm Settings, as shown below:
