xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
393
Figure 9-6 DHCP Relay Option 60 Settings window
The fields that can be configured are described below:
Parameter Description
String
Enter the DHCP Relay Option 60 String value. Different strings can be specified for the
same relay server, and the same string can be specified with multiple relay servers.
The system will relay the packet to all the matching servers.
Enter the DHCP Relay Option 60 Server IP address.
Match Type
Enter the DHCP Relay Option 60 Match Type value.
Exact Match – The option 60 string in the packet must full match with the specified
string.
Partial Match – The option 60 string in the packet only need partial match with the
Enter the DHCP Relay Option 60 IP address.
Enter the DHCP Relay Option 60 String value.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete button to remove the specific entry based on the information entered.
Click the Show All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
Click the Delete button to remove the specific entry.
DHCP Relay Option 61 Settings
On this page the user can configure, add and delete DHCP relay option 61 parameters.
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Option 61 Settings as
shown below:
Figure 9-7 DHCP Relay Option 61 Settings window
