xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
237
Remote AS Number
(0-65535)
Enter the number of the autonomous system to which the peer group belongs to. The
range is from 0 to 65535.
Click the Apply button to accept the changes made.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the View All button to display all the existing entries.
Click the
View Detail
Click the Delete button to remove the specific entry.
link to view more information regarding the specific entry.
Click the
View Detail link to see the following window.
Figure 5-118 BGP Peer Group Settings - View Detail window
Click the <<Back button to return to the previous window.
BGP Neighbor
BGP Neighbor Group Settings
This window is used to configure a Border Gateway Protocol (BGP) neighbor group.
To view the following window, click L3 Features > BGP > BGP Neighbor > BGP Neighbor Group Settings, as
shown below:
Figure 5-119 BGP Neighbor Group Settings window
The fields that can be configured are described below:
Parameter Description
Peer Group Name
Enter the name of the BGP peer group.
IP Address
Enter the IP address of the BGP speaking neighbor.
