xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
200
RX Mode Specifies the RIP receive mode Options to choose from are v1 Only, v2 Only and v1 or v2.
Select Disable to disable this option.
State
Specifies that the RIP state will be enabled or disabled. If the state is disabled, then RIP
packets will not be either transmitted or received by the interface. The network configured
on this interface will not be in the RIP database.
Authentication
Specifies to set the state of authentication. When the authentication state is enabled, enter
the password used in the space provided.
Click the Apply button to accept the changes made.
Click the <<Back button to return to the previous window.
RIPng (EI Mode Only)
The Switch supports Routing Information Protocol next generation (RIPng). RIPng is a routing protocol that
exchanges routing information used to compute routes and is intended for IPv6-based networks.
RIPng Global Settings
This window allows users to set up RIPng.
To view the following window, click L3 Features > RIP>RIPng > RIPng Global Settings, as shown below:
Figure 5-63 RIPng Global Settings window
The fields that can be configured are described below:
Parameter Description
RIPng State
Click the radio buttons to enable or disable RIPng globally. The default setting is
Disabled.
Method Use the drop-down menu to choose from No Horizon, Split Horizon, and Poison
Reverse.
No Horizon – Configured to not use any horizon.
Split Horizon – Configured to use basic split horizon. This is the default setting.
Poison Reverse – Configured to use split horizon with poison reverse.
Update Time (5-65535)
Enter the value, in seconds, of the update timer.
Expire Time (1-65535)
Enter the interval, in seconds, of the expire timer.
Garbage Collection
Time (1-65535)
Enter the value, in seconds, of the garbage collection timer.
Click the Apply button to accept the changes made.
