xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
459
Log Type Select the type of log to be transferred. Selecting the Common Log option here will
upload the common log entries. Selecting the Attack Log option here will upload the log
concerning attacks.
Click Upload to initiate the upload.
Upload Log to HTTP
This window allows the user to upload the log file from the Switch to a computer.
Figure 12-19 Upload Log to HTTP window
The fields that can be configured are described below:
Parameter Description
Log Type Select the type of log to be transferred. Selecting the Common Log option here will
upload the common log entries. Selecting the Attack Log option here will upload the log
Click Upload to initiate the upload.
Reset
The Reset function has several options when resetting the Switch. Some of the current configuration parameters
can be retained while resetting all other configuration parameters to their factory defaults.
NOTE: Only the Reset System option will enter the factory default parameters into the Switch's non-
volatile RAM, and then restart the Switch. All other options enter the factory defaults into the
current configuration, but do not save this configuration. Reset System will return the Switch's
configuration to the state it was when it left the factory
Reset gives the option of retaining the Switch's User Accounts and History Log while resetting all other
configuration parameters to their factory defaults. If the Switch is reset using this window, and Save Changes is
not executed, the Switch will return to the last saved configuration when rebooted.
Figure 12-20 Reset System window
The fields that can be configured are described below:
Parameter Description
Reset Selecting this option will factory reset the Switch but not the IP Address, User
Selecting this option will factory reset the Switch but not perform a Reboot.
Selecting this option will factory reset the Switch and perform a Reboot.
