xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
254
Figure 5-145 IP Prefix List Settings - View Detail window
The fields that can be configured are described below:
Parameter Description
Sequence ID (1-
65535)
Enter the sequence number for the rule entry.
Direction
Use the drop-down menu to Permit or Deny the specified network.
Prefix Address
Enter the network address.
Prefix Mask
Enter the mask address of the network address.
GE (1-32)
Enter the minimum prefix length to be matched.
LE (1-32)
Enter the maximum prefix length to be matched.
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to return to the previous window.
Click the Edit button to re-configure the specific entry.
Click the Clear button to delete the information in the Description.
IP Standard Access List Settings
This window is used to create an access list used to filter routes.
To view the following window, click L3 Features > IP Route Filter > IP Standard Access List Settings, as shown
below:
Figure 5-146 IP Standard Access List Settings window
The fields that can be configured are described below:
Parameter Description
Access List Name
Enter the name of the access list.
Click the Find button to locate a specific entry based on the information entered.
Click the Add button to add a new entry based on the information entered.
