xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
419
The fields that can be configured are described below:
Parameter Description
Unit
Specifies the unit’s ID used.
From Port / To Port
Use the drop-down menu to select a range of ports used for this configuration.
State
Use the drop-down menu to enable or disable the state of specific port regarding the
CFM configuration.
Click the Apply button to accept the changes made.
CFM MIPCCM Table
This window is used to display CFM MIPCCM information.
To view this window, click OAM > CFM > CFM MIPCCM Table, as shown below:
Figure 10-11 CFM MIPCCM Table Window
CFM Loopback Settings
This window is used to CFM loopback settings.
To view this window, click OAM > CFM > CFM Loopback Settings, as shown below:
Figure 10-12 CFM Loopback Settings Window
The fields that can be configured are described below:
Parameter Description
MEP Name
Select and enter the Maintenance End Point name used.
MEP ID (1-8191)
Select and enter the Maintenance End Point ID used.
MD Name
Select and enter the Maintenance Domain name used.
MD Index
Select and enter the Maintenance Domain index used.
MA Name
Select and enter the Maintenance Association name used.
