xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
130
IPv6 Limited Multicast Range Settings
Users can configure the ports and VLANs on the Switch that will be involved in the Limited IPv6 Multicast Range.
To view the following window, click L2 Features > Multicast Filtering > IPv6 Multicast Filtering > IPv6 Limited
Multicast Range Settings, as show below:
Figure 4-96 IPv6 Limited Multicast Range Settings window
The fields that can be configured are described below:
Parameter Description
Select the appropriate port(s) or VLAN IDs used for the configuration here.
Assign access permissions to the ports selected. Options listed are Permit and Deny.
Use the drop-down menu to select the profile ID or profile name used and then assign
Permit or Deny access to them.
Click the Apply button to accept the changes made.
Click the Add button to add a new entry based on the information entered.
Click the Delete button to remove the specific entry.
Click the Find button to locate a specific entry based on the information entered.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
IPv6 Max Multicast Group Settings
Users can configure the ports and VLANs on the switch that will be a part of the maximum filter group, up to a
maximum of 1024.
Figure 4-97 IPv6 Max Multicast Group Settings window
The fields that can be configured are described below:
Parameter Description
Select the appropriate port(s) or VLAN IDs used for the configuration here.
