xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
363
Figure 8-53 Port Security Port-VLAN Settings window
The fields that can be configured are described below:
Parameter Description
Click the radio button and enter a VLAN name.
Click the radio button and enter a list of VLAN ID.
Max Learning Address
(0-3328)
Enter the maximum number of port security entries that can be learned by this VLAN.
If this parameter is set to 0, it means that no user can be authorized on this VLAN.
If the setting is lower than the number of current learned entries on the VLAN, the
command will be rejected. Tick the No Limit check box to have unlimited number of
port security entries that can be learned by a specific VLAN.
The default value is No Limit.
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.
Port Security VLAN Settings
This window is used to configure the maximum number of port-security entries that can be learned on a specific
VLAN.
To view this window, click Security > Port Security > Port Security VLAN Settings as shown below:
Figure 8-54 Port Security VLAN Settings window
The fields that can be configured are described below:
Parameter Description
Click the radio button and enter the VLAN Name.
Click the radio button and enter a list of the VLAN ID.
Max Learning
Address (0-3328)
Enter the maximum number of port-security entries that can be learned by this VLAN.
Tick the No Limit check box to have unlimited number of port-security entries that
can be learned by this VLAN.
Click the Apply button to accept the changes made.
