xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
59
Figure 3-48 SNMP community Maskking Settings window
The fields that can be configured are described below:
Parameter Description
Use the drop-down menu to choose the MIB view name.
Access right
Use the drop-down menu to select the access right for the user using the
community string. Available options are Read Only and Read Write.
Enter a case-sensitive
Enter a case-sensitive community string.
Enter the community
Retype the community string for confirmation.
Click the Apply button to accept the changes made.
Telnet Settings
Users can configure Telnet Settings on the Switch.
To view the following window, click Management > Telnet Settings, as show below:
Figure 3-49 Telnet Settings window
The fields that can be configured are described below:
Parameter Description
Telnet State
Telnet configuration is Enabled by default. If you do not want to allow configuration of the
system through Telnet choose Disabled.
Port (1-65535)
The TCP port number used for Telnet management of the Switch. The “well-known” TCP
port for the Telnet protocol is 23.
Click the Apply button to accept the changes made.
Web Settings
Users can configure the Web settings on the Switch.
To view the following window, click Management > Web Settings, as show below:
