D-Link DGS-3620-28PC-SI User Manual

xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
430
Show/Hide
Check whether or not to display Five Seconds, One Minute, and Five Minutes.
Click the Apply button to accept the changes made.
DRAM & Flash Utilization
This window is used to display information regarding the DRAM and Flash utilization.
To view this window, click Monitoring > Utilization > DRAM & Flash Utilization as shown below:
Figure 11-2 DRAM & Flash Utilization window
Port Utilization
This window is used to display the percentage of the total available bandwidth being used on the port.
To view this window, click Monitoring > Utilization > Port Utilization as shown below:
Figure 11-3 Port Utilization window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit you want to configure.

D-Link DGS-3620-28PC-SI Specifications

General

Brand	D-Link
Model	DGS-3620-28PC-SI
Category	Switch
Language	English
