xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
124
After clicking the Group List link, the following page will appear:
Figure 4-86 Multicast Group Profile Multicast Address Settings window
The fields that can be configured are described below:
Parameter Description
Enter the multicast address list.
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to discard the changes made and return to the previous page.
Click the Delete button to remove the specific entry.
MLD Snooping Multicast VLAN Settings
Users can add, delete, or configure the MLD snooping multicast VLAN on this page.
To view the following window, click L2 Features > L2 Multicast Control > Multicast VLAN > MLD Snooping
Multicast VLAN Settings, as show below:
Figure 4-87 MLD Snooping Multicast VLAN Settings window
The fields that can be configured are described below:
Parameter Description
MLD Multicast VLAN
Click the radio buttons to enable or disable the MLD multicast VLAN state.
MLD Multicast VLAN
Click the radio buttons to can enable or disable the MLD multicast VLAN Forward
Enter the VLAN name used.
Enter the VID value used.
Remap Priority
The user can select this option to enable the Remap Priority feature.
Specify the remap priority (0 to 7) to be associated with the data traffic to be
forwarded on the multicast VLAN. If None is specified, the packet’s original priority
will be used. The default setting is None.
Replace Priority
Tick the check box to specify that the packet’s priority will be changed by the switch,
based on the remap priority. This flag will only take effect when the remap priority is
