xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
253
IP Route Filter
IP Prefix List Settings
This window is used to create and configure an IP prefix list.
To view the following window, click L3 Features > IP Route Filter > IP Prefix List Settings, as shown below:
Figure 5-143 IP Prefix List Settings window
The fields that can be configured are described below:
Parameter Description
Prefix List Name
Enter the name to identify the prefix list.
Click the Find button to locate a specific entry based on the information entered.
Click the Add button to add a new entry based on the information entered.
Click the View All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
Click the Clear Counter button to see the clear counter window.
Click the
View Detail
Click the Edit button to re-configure the specific entry.
link to view more information regarding the specific entry.
Click the Clear button to delete the information in the Description.
Click the Delete button to remove the specific entry.
Click the Clear Counter button to see the following window.
Figure 5-144 IP Prefix List Settings - Clear Counter window
The fields that can be configured are described below:
Parameter Description
Prefix List Name
Enter the name of the prefix list that will be cleared.
IP Address
Enter the IP address to be cleared.
Mask Address
Enter the mask address to be cleared.
Click the Clear button to remove the information entered.
Click the <<Back button to return to the previous window.
Click the Clear All button to remove all the entries.
Click the
View Detail link to see the following window.
