xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
332
Figure 8-21 Reauthenticate Host-based Port(s) window
The fields that can be configured are described below:
Parameter Description
Select a unit you want to display.
Use the drop-down menus to select a range of ports to display.
Tick the check box and enter the MAC address.
Click the Apply button to accept the changes made.
RADIUS
Authentication RADIUS Server Settings
The RADIUS feature of the Switch allows the user to facilitate centralized user administration as well as providing
protection against a sniffing, active hacker.
To view this window, click Security > RADIUS > Authentication RADIUS Server Settings as shown below:
Figure 8-22 Authentication RADIUS Server Settings window
The fields that can be configured are described below:
Parameter Description
Index Choose the desired RADIUS server to configure: 1, 2 or 3 and select the IPv4
Set the RADIUS server IP address.
Set the RADIUS server IPv6 address.
Set the RADIUS authentication server(s) UDP port which is used to transmit
RADIUS data between the Switch and the RADIUS server.
Accounting Port (1-65535)
Set the RADIUS account server(s) UDP port which is used to transmit RADIUS
accounting statistics between the Switch and the RADIUS server.
Set the RADIUS server age-out, in seconds.
