xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
357
JWAC Authentication State
This window is used to display Japanese Web-based Access Control Host Table information.
To view this window, click Security > Japanese Web-based Access Control (JWAC) > JWAC Authentication
State as shown below:
Figure 8-45 JWAC Authentication State Window
The fields that can be configured are described below:
Parameter Description
Port List
Enter a port or range of ports.
Authenticated
Tick this check box to only clear authenticated client hosts.
Authenticating
Tick this check box to only clear client hosts in the authenticating process.
Blocked
Tick this check box to only clear client hosts being temporarily blocked because of the
failure of authentication.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear button to remove entry based on the port list entered.
Click the View All Hosts button to display all the existing entries.
Click the Clear All Hosts button to remove all the entries listed.
JWAC Customize Page Language
Users can configure JWAC page and language settings for the Switch. The current firmware supports either
English or Japanese.
To view this window, click Security > Japanese Web-based Access Control (JWAC) > JWAC Customize Page
Language as shown below:
Figure 8-46 JWAC Customize Page Language Window
The fields that can be configured are described below:
Parameter Description
Customize Page Language
Click the radio buttons to select English or Japanese.
Click the Apply button to accept the changes made.
