xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
421
Click the Delete All button to remove all the entries listed.
CFM Packet Counter
This window is used to display the CFM packet counter information. This window does not count CCM packet
statistics of the MEPs in CFM hardware mode.
To view this window, click OAM > CFM > CFM Packet Counter, as shown below:
Figure 10-14 CFM Packet Counter Window
The fields that can be configured are described below:
Parameter Description
Port List Enter a port or range of ports to display. Tick the All Ports check box to display all
Type Transmit – Selecting this option will display all the CFM packets transmitted.
Receive – Selecting this option will display all the CFM packets received.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear button to clear all the information entered in the fields.
CFM Fault Table
This window is used to display the CFM fault information.
To view this window, click OAM > CFM > CFM Fault Table, as shown below:
