xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
458
Upload Log File
The following window is used to upload the log file from the Switch.
Upload Log to TFTP
This window allows the user to upload the log file from the Switch to a TFTP Server.
Figure 12-17 Upload Log – TFTP window
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Enter the TFTP server IP address used.
Click the radio button to enter the TFTP server IP address used.
Click the radio button to enter the TFTP server IPv6 address used.
Click the radio button to enter the domain name.
Enter the location and name of the Destination File.
Log Type Select the type of log to be transferred. Selecting the Common Log option here will
upload the common log entries. Selecting the Attack Log option here will upload the log
Click Upload to initiate the upload.
Upload Log to RCP
This window allows the user to upload the log file from the Switch to a RCP Server.
Figure 12-18 Upload Log to RCP window
The fields that can be configured are described below:
Parameter Description
RCP Server IP
Enter the RCP Server IP Address used.
User Name
Enter the appropriate Username used.
Destination File
Enter the location and name of the Destination File.
