xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
118
Figure 4-76 MLD Snooping Group window
The fields that can be configured are described below:
Parameter Description
VLAN Name
Click the radio button and enter the VLAN name of the multicast group.
VID List
Click the radio button and enter a VLAN list of the multicast group.
Port List
Specify the port number(s) used to find a multicast group.
Group IPv6 Address
Enter the group IPv6 address used here.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the existing entries.
MLD Snooping Forwarding Table
This page displays the switch’s current MLD snooping forwarding table. It provides an easy way for user to check
the list of ports that the multicast group comes from and specific sources that it will be forwarded to. The packet
comes from the source VLAN. They will be forwarded to the forwarding VLAN. The MLD snooping further restricts
the forwarding ports.
To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping
Forwarding Table, as show below:
Figure 4-77 MLD Snooping Forwarding Table window
The fields that can be configured are described below:
Parameter Description
VLAN Name The name of the VLAN for which you want to view MLD snooping forwarding table
information.
VID List
The ID of the VLAN for which you want to view MLD snooping forwarding table information.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the existing entries.
