xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
12
Figure 2-4 Port Description Settings window
The fields that can be configured are described below:
Parameter Description
Select the unit you wish to configure.
Select the appropriate port range used for the configuration here.
Medium Type
Specify the medium type for the selected ports. If configuring the Combo ports, the
Medium Type defines the type of transport medium to be used, whether Copper or Fiber.
Users may then enter a description for the chosen port(s).
Click the Apply button to implement changes made.
Port Error Disabled
The following window displays the information about ports that have been disconnected by the Switch when a
packet storm occurs or a loop was detected.
To view the following window, click System Configuration > Port Configuration > Port Error Disabled, as show
below:
Figure 2-5 Port Error Disabled
