xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
107
Port List
Enter the port list used for this configuration.
VID List
Enter the VID list used for this configuration.
Rate Limit (1-
1000)
Enter the IGMP snooping rate limit used. By selecting the No Limit check box, the rate
limit for the entered port(s) will be ignored.
Click the Apply button to accept the changes made.
Click the Find button to locate a specific entry based on the information entered.
Click the Edit button to re-configure the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
IGMP Snooping Static Group Settings
Users can view the Switch’s IGMP Snooping Group Table. IGMP Snooping allows the Switch to read the Multicast
Group IP address and the corresponding MAC address from IGMP packets that pass through the Switch.
To view the following window, click L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping
Static Group Settings, as show below:
Figure 4-58 IGMP Snooping Static Group Settings window
The fields that can be configured are described below:
Parameter Description
VLAN Name
The VLAN Name of the multicast group.
VID List
The VID List or of the multicast group.
IPv4 Address
Enter the IPv4 address.
Click the Find button to locate a specific entry based on the information entered.
Click the Create button to add a new entry based on the information entered.
Click the Delete button to remove the specific entry based on the information entered.
Click the View All button to display all the existing entries.
Click the Edit button to re-configure the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Edit button, the following page will appear:
