xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
157
Figure 5-6 Policy Route Settings - Edit window
The fields that can be configured are described below:
Parameter Description
Profile ID (1-6)
Enter the ACL profile ID.
Access ID (1-256)
Enter the ACL access ID.
Next Hop IPv4 Address
Enter the next hop IP address.
State
Use the drop-down menu to enable or disable this rule.
Click the <<Back button to return to the previous window.
Click the Apply button to accept the changes made.
IP Forwarding Table
The IP forwarding table stores all the direct connected IP information. On this page the user can view all the direct
connected IP information.
To view the following window, click L3 Features > IP Forwarding Table, as show below:
Figure 5-7 IP Forwarding Table
Click the IP Address, Interface Name or Port radio button, enter the information and click the Find button to
locate a specific entry based on the information entered.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
IP Multicast Forwarding Table
This window will show current IP multicasting information on the Switch.
To view the following window, click L3 Features > IP Multicast Forwarding Table, as shown below:
