xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
399
DHCPv6 Server Global
State
Click the radio buttons to enable or disable the DHCPv6 Server State.
Click the Apply button to accept the changes made.
DHCPv6 Server Pool Settings
This window is used to create and configure a DHCPv6 pool.
To view this window, click Network Application > DHCP > DHCPv6 Server > DHCPv6 Server Pool Settings as
shown below:
Figure 9-16 DHCPv6 Server Pool Settings window
The fields that can be configured are described below:
Parameter Description
Pool Name
Enter the DHCPv6 Server Pool name.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the View All button to display all the existing entries.
Click the Edit button under various columns to re-configure the specific entry.
Click the Delete button to remove the specific entry.
Click the Edit button under Excluded Address to see the following window.
Figure 9-17 DHCPv6 Server Excluded Address Settings window
The fields that can be configured are described below:
Parameter Description
Begin Address
Enter the beginning IPv6 address of the range of IPv6 addresses to be excluded from
the DHCPv6 pool.
End Address
Enter the ending IPv6 address of the range of IPv6 addresses to be excluded from the
DHCPv6 pool.
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to return to the previous window.
Click the Delete All button to remove all the entries listed.
To Next Page
