xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
110
Click the View All button to display all the existing entries.
IGMP Snooping Counter
Users can view the switch’s IGMP Snooping counter table.
To view the following window, click L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping
Counter, as show below:
Figure 4-63 IGMP Snooping Counter window
The fields that can be configured are described below:
Parameter Description
The VLAN Name of the multicast group.
The VLAN ID list of the multicast group.
The Port List of the multicast group.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the existing entries.
Click the
Packet Statistics
link to view the IGMP Snooping Counter Table.
After clicking the
Packet Statistics link, the following page will appear:
Figure 4-64 Browse IGMP Snooping Counter window
Click the Clear Counter button to clear all the information displayed in the fields.
Click the Refresh button to refresh the display table so that new information will appear.
Click the <<Back button to return to the previous page.
