xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
161
External - To redistribute only the OSPF AS-external routes, including Ext Type1 and
Ext Type2 routes.
Ext Type1 - To redistribute only the OSPF AS-external type-1 routes.
Ext Type2 - To redistribute only the OSPF AS-external type-2 routes.
Inter-E1 - To redistribute only the OSPF AS-external type-1 and OSPF AS-internal
routes.
Inter-E2 - To redistribute only the OSPF AS-external type-2 and OSPF AS-internal
Enter the RIP metric value for the redistributed routes.
Route Map Name
Enter a route map which will be used as the criteria to determine whether to
redistribute specific routes.
Click the Apply button to accept the changes made for each individual section.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
IP Tunnel (EI Mode Only)
IP Tunnel Settings
This window is used to configure IP Tunnel Settings.
To view the following window, click L3 Features > IP Tunnel > IP Tunnel Settings, as shown below:
Figure 5-14 IP Tunnel Settings window
The fields that can be configured are described below:
Parameter Description
Enter the IP tunnel interface name.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the existing entries.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
Click the Edit button to see the following window.
