xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
150
delay time of an event message.
E2E - The port is configured to use the delay request-response mechanism.
P2P - The peer delay mechanism.
Delay Request
Interval (0-5)
Enter the permitted mean time interval between successive delay request messages
which are sent by a slave to a specific port on the master. This mean time interval
value is determined and advertised by a master.
Enter the permitted mean time interval between successive pdelay_request
Enter the mean time interval between successive Sync messages. Referred to as
syncInterval. Tick the Half Second check box to have the 0.5 second of syncInterval.
Click the Apply button to accept the changes made.
PTP Peer to Peer Transparent Port Settings
This window is used to configure the Pdelay Request Interval of the P2P transparent clock.
To view this window, click L2 Features > PTP > PTP Peer to Peer Transparent Port Settings, as shown below:
Figure 4-122 PTP Peer to Peer Transparent Port Settings window
The fields that can be configured are described below:
Parameter Description
Select a unit you want to configure.
Select the port range to use for this configuration.
Enter the permitted mean time interval between successive pdelay_request
Click the Apply button to accept the changes made.
