xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
129
IPv6 Multicast Profile Settings
Users can add, delete, and configure the IPv6 multicast profile on this page.
To view the following window, click L2 Features > Multicast Filtering > IPv6 Multicast Filtering > IPv6 Multicast
Profile Settings, as show below:
Figure 4-94 IPv6 Multicast Profile Settings window
The fields that can be configured are described below:
Parameter Description
Enter a Profile ID between 1 and 60.
Enter a name for the IP Multicast Profile.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the
Group List
Click the Edit button to re-configure the specific entry.
link to configure the multicast address group list settings for the specific entry.
Click the Delete button to remove the specific entry.
After clicking the
Group List link, the following page will appear:
Figure 4-95 Multicast Address Group List Settings window
The fields that can be configured are described below:
Parameter Description
Enter the multicast address list here.
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to discard the changes made and return to the previous page.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
