xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
418
Figure 10-9 CFM Extension LCK Settings (Edit) Window
The fields that can be configured are described below:
Parameter Description
Tick the check box and use the drop-down menu to enable or disable the LCK function.
Period
Tick the check box and use the drop-down menu to select the transmitting interval of
Level
Tick the check box and use the drop-down menu to select the client level ID to which
the MEP sends LCK PDU. The default client MD level is MD level at which the most
immediate client layer MIPs and MEPs exist. Options to choose from are values
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.
CFM Port Settings
This window is used to configure the CFM port state.
To view this window, click OAM > CFM > CFM Port Settings, as shown below:
Figure 10-10 CFM Port Settings Window
