xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
116
Enter the Port List here.
Enter the VID List value here.
Rate Limit
Configure the rate limit of MLD control packet that the switch can process on a
specific port/VLAN. The rate is specified in packet per second. The packet that
exceeds the limited rate will be dropped. Selecting the No Limit option lifts the rate
Click the Apply button to accept the changes made for each individual section.
Click the Find button to locate a specific entry based on the information entered.
Click the Edit button to re-configure the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
MLD Snooping Static Group Settings
This page used to configure the MLD snooping multicast group static members.
To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping
Static Group Settings, as show below:
Figure 4-73 MLD Snooping Static Group Settings window
The fields that can be configured are described below:
Parameter Description
The name of the VLAN on which the static group resides.
The ID of the VLAN on which the static group resides.
Specify the multicast group IPv6 address.
Click the Find button to locate a specific entry based on the information entered.
Click the Create button to add a static group.
Click the Delete button to delete a static group.
Click the View All button to display all the existing entries.
Click the Edit button to re-configure the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Edit button, the following page will appear:
