xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
119
MLD Snooping Counter
This page displays the statistics counter for MLD protocol packets that are received by the switch since MLD
Snooping is enabled.
To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping
Counter, as show below:
Figure 4-78 MLD Snooping Counter window
The fields that can be configured are described below:
Parameter Description
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the existing entries.
Click the
Packet Statistics
link to view the MLD Snooping Counter Settings for the specific entry.
After clicking the
Packet Statistics link, the following page will appear:
Figure 4-79 Browse MLD Snooping Counter window
Click the Clear Counter button to clear all the information displayed in the fields.
Click the Refresh button to refresh the display table so that new information will appear.
Click the <<Back button to return to the previous page.
