xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
429
Chapter 11 Monitoring
Utilization
Statistics
Mirror
sFlow
Ping
Trace Route
Peripheral
Utilization
CPU Utilization
This window is used to display the percentage of the CPU being used, expressed as an integer percentage and
calculated as a simple average by time interval.
To view this window, click Monitoring > Utilization > CPU Utilization as shown below:
Figure 11-1 CPU Utilization window
To view the CPU utilization by port, use the real-time graphic of the Switch and/or switch stack at the top of the web
page by simply clicking on a port. Click Apply to implement the configured settings. The window will automatically
refresh with new updated statistics.
The fields that can be configured are described below:
Parameter Description
Time Interval Select the desired setting between 1s and 60s, where "s" stands for seconds. The
