xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
72
Parameter Description
Click the radio buttons to enable or disable the GVRP State.
Enter the Join Time value in milliseconds.
Leave Time
Enter the Leave Time value in milliseconds.
Leave All Time
Enter the Leave All Time value in milliseconds.
NNI BPDU Address
Used to determine the BPDU protocol address for GVRP in service provide site. It can
use 802.1d GVRP address, 802.1ad service provider GVRP address or a user defined
multicast address. The range of the user defined address is 0180C2000000 -
Click the Apply button to accept the changes made for each individual section.
NOTE: The Leave Time value should be greater than twice the Join Time value. The Leave All Time
value should be greater than the Leave Time value.
GVRP Port Settings
On this page the user can configure the GVRP port parameters.
To view the following window, click L2 Features > VLAN > GVRP > GVRP Port Settings, as show below:
Figure 4-12 GVRP Port Settings window
The fields that can be configured are described below:
Parameter Description
Select the unit you want to configure.
Select the starting and ending ports to use.
