4. AIS OPERATION
4-21
4.18 Other AIS Features
The [TT•AIS] menu additionally provides the features described below.
[2 ATON SYMBOL COLOR]: Select the ATON symbol color.
[3 AIS ROT TAG LIMIT]: The ROT marker appears on the heading line of an AIS tar-
get and points in the direction of the turn when the ship's rate of turn is greater than
that set here.
[1 AIS SCALED SYMBOL]: The AIS target symbol can be shown as a simple triangle
or a symbol scaled according to a vessels’ dimensions. Select [ON] to show the scaled
symbol.
Page 2
Page 1
Standard
AIS symbol
AIS
scaled symbol
To Next Page
