6. CHART OVERVIEW
6-22
6.10.4 EBL, VRM functions available with the context-sensitive menu
The EBLs and VRMs have additional functions that are accessed from the context-
sensitive menu. Right-click any VRM or EBL box to show the context-sensitive menu.
Function Description
[Centered] Centers the origin of the EBL and VRM on the current position.
[Ground] Anchors the EBL and VRM to ground; neither the EBL or VRM move
with ship's movement.
[Offset HDG]
[Offset North]
Select
[Offset
HDG].
Drag and drop EBL, VRM
on desired location.
When vessel changes course, the
EBL, VRM move so that the range (L)
to their centers stays fixed.
Drag and drop EBL, VRM
on desired location.
The EBL, VRM move to keep the
angle from North to the center of the
EBL, VRM, even if the vessel
changes course. The distance to the
center of the EBL, VRM is fixed.
Select
[Offset
North].
To Next Page
