APPENDIX 1 MENU TREE
Radar menu
1 ECHO 1 CUSTOMIZE
ECHO
2 ECHO AREA* (CIRCLE, WIDE)
3 ECHO COLOR (YEL, GRN, WHT, AMBER*, COLOR*)
4 TRAIL
5 2ND ECHO REJ (OFF, ON)
6 PERFORMANCE MON (OFF, ON)
7 SART (OFF, ON)
8 WIPER (OFF, 1, 2)
9 DUAL RADAR (OFF, COMBINE)
1 INT REJECT (
OFF
, 1, 2, 3)
2 ECHO STRETCH (
OFF
, 1, 2, 3)
3 ECHO AVERAGE (
OFF
, 1, 2, 3)
4 NOISE REJECT (
OFF
, ON)
5 AUTO SEA (
OFF
, ON)
6 AUTO RAIN (
OFF
, 1, 2, 3, 4)
7 VIDEO CONTRAST (
1
, 2, 3, 4; A,
B
, C)
8 PULSE
9 CONDITION
0 DEFAULT (
NO
, SAVE, USER, DEFAULT)
1 0.5 NM (S1, S2)
2 0.75 NM (S1, S2, M1)
3 1.5 NM (S1, S2, M1)
4 3 NM (S2, M1, M2, M3)
5 6 NM (M1, M2, M3, L)
6 12-24 NM (M2, M3, L)
1 SEA CONDITION (1, 2, 3, 4, 5)
2 STC ANT HEIGHT (5, 7.5, 10, 15, 20, 25,
30, 35, 40, 45, more 45 m)
3 LOW LEVEL ECHO (0 to 8, 0)
4 STC RANGE (-10 to +10, 0)
1 TRAIL MODE (REL, TRUE)
2 TRAIL GRAD (SINGLE, MULTI)
3 TRAIL COLOR* (GRN, BLU, CYA, PNK,
MAG, WHT, YEL)
4 TRAIL LEVEL (1, 2, 3, 4)
5 OS TRAIL (OFF, ON)
6 SUPPRESS TRAIL AROUND OS (OFF, ON)
2 TT/AIS
1 ACQUISITION ZONE
2 TRIAL MANEUVER
3 TT
4 AIS
1 AZ STAB (STAB HDG, STAB NORTH)
2 AZ POLYGON (OFF, STAB GND, STAB
HDG, STAB NORTH)
1 TRIAL MANEUVER (STATIC, DYNAMIC)
2 SPEED RATE
3 TURN RATE
4 TGT DATA* (ACTUAL, TRIAL)
1 TT SELECT**
2 ALL CANCEL (NO, YES)
3 LOST FILTER MAX RNG (OFF, ON
(0 to 99 NM, 12))
1 VOYAGE DATA (NAV STATUS, ETA,
DESTINATION, DRAUGHT, CREW, PERSONS,
CARGO CATEGORY)
2 STATIC DATA
3 SLEEP ALL TGTS (NO, YES)
4 CPA AUTO ACTIVATE
5 DISP FILTER
1 MAX RANGE (OFF, ON (0 to 99 NM, 12))
2 MIN SHIP SPEED (OFF, ON
(0-9.9 kn, 1.0))
3 EXCEPT CLASS B (OFF, ON)
1 SLEEPING CLASS A (OFF, ON)
2 SLEEPING CLASS B (OFF, ON)
3 BASE STATION (OFF, ON)
4 PHYSCIAL ATON (OFF, ON)
5 VIRTUAL ATON (OFF, ON)
6 MAX RANGE (OFF, ON (0 to 99 NM, 12))
7 MIN SHIP SPEED (OFF, ON
(0-9.9 kn, 1.0))
(Continued on next page)
* Not available with
IMO or A type.
**: When [NUMBER OF TT] is [MAX]:
(MANUAL 100, MANUAL 75•AUTO 25,
MANUAL 50•AUTO 50, MANUAL 25•AUTO 75,
AUTO 100)
